DESCRIPTION
The constant temperature shaker has a stainless-steel universal clamp, digital display temperature control, stepless speed regulation and good thermal cycle function. It is a multi-purpose biochemical device, which is a plant, biology, microbiology, genetics, virus, environmental protection, medicine and other scientific research. education and production departments for precision culture preparation of indispensable laboratory equipment.
FEATURES
1. The original technology of the original single-axis drive balance device 1(patent type: a single-axis drive swing balance mechanism; patent number: ZL 2015 2 0624431.5), to ensure minimum energy consumption and noise.
2. Vertical double-layer structure, small footprint, large bottle capacity and double performance.
3. The oscillation frequency can be extended over a wide range to 50-300 rpm.
4. Intelligent sound and light alarm environment scanning microprocessor controller.
5. The LCD large-screen backlit LCD display double displays each set parameter and measured parameter.
6. Model 2102C/2102/2112B/F is a safe, fluorine-free refrigeration system that meets international environmental requirements.
7. Run the parameter memory function to avoid cumbersome operations.
8. AC induction long life motor design, wide speed regulation, constant torque, constant speed, no carbon brush, maintenance free.
9. Over-temperature sound and light alarm function, motor overheating, temperature out of control, abnormal over-temperature instrument automatically cut off their respective power supply.
10. With power-off recovery function, after the external power supply suddenly loses power and calls again, the device can automatically resume operation according to the original setting program.
11. The line that controls the acceleration ensures that the shaker is slowly started and smoothly accelerated to ensure the safety of the experimental samples.
12. The streamlined luxury machine model with rich aesthetic design concept, electrostatic spray box, large screen tempered glass window.
13. Timing setting up to 500 hours, and sound and light alarm
14. Adapt to the increasing trend of sample processing in modern laboratories and the mass production of modern bioengineering.
15. The front door opening design allows the shaker to be more flexible than turning the door shaker up.
16. Available in both temperature and low temperature ranges.
17. Efficient drive Makeda and refrigeration control, ultra-low energy consumption.
18. The transparent viewing window and built-in lighting design make it easy to view samples at any time.
19. Simultaneous observation of temperature, oscillation speed, time
Application range
Cell culture
Solubility test
Extraction experiment
Diagnostic test
Mixing samples
Bacterial suspension preparation
Dyeing and bleaching
Elution process
Hybrid experiment
Security
Leakage current and overcurrent protection systems ensure operator safety.
Over-temperature, over-speed sound and light alarm emergency control system to ensure sample safety
SPECIFICATIONS
| Product number | OH-1102C | OH-2102C | |
| control method | P.I.D(Microcomputer environment scanning micro processing chip) | ||
| Display method | LCD (Large screen LCD dual display) | ||
| Cyclic mode | Forced convection | ||
| Oscillation mode | Rotary oscillation | ||
| Drive mode | Single-axis balancing device (Chinese patent) | ||
| Environmental requirements | Temperature 25 ° C, humidity 20% -90% | ||
| Opening method | Single door | ||
| Temperature control range | Room temperature +5℃-60℃ | 4-60℃ | |
| Temperature accuracy | ±0.1℃ | ||
| Temperature uniformity | ±1℃ | ||
| Performance | Frequency Range | 30-300rpm | |
| Rotation accuracy | ±1rpm | ||
| Pendulum amplitude | Φ25mm | ||
| security function | Upper and lower temperature deviation alarm; upper- and lower-line speed deviation alarm, independent over-temperature protector; open door stop protection; leakage protection, chiller overload protection. | ||
| Accessory function | Speed storage, call recovery, parameter memory, temperature speed correction, clock display, room temperature / measured temperature double display. | ||
| Programming function | Repeat, step, eight-segment curve programming settings. | ||
| The refrigerant | – | CFC-Free (134A) fluorine-free safety refrigeration system | |
| Cooler | – | 200W | |
| Heater | 500W | ||
| Timing range | 0-999.59h/ Sustainable | ||
| Standard sizes | Rocker size | 500*350(mm) | |
| Number of rocking plates | Two | ||
| Gross weight | 150kg | 165kg | |
| Inner cavity size | 600*440*650H (mm) | ||
| Dimensions | 700*600*1250H(mm) | ||
| power | 600W | 830W | |
| power supply | AC 200-240V 50-60HZ | ||
| Materia | Motor | 120W inverter motor | |
| Inner cavity material | High quality imported stainless steel mirror panel | ||
| box Materia | High qualitychannel steel, angle steel, cold rolled steel plate | ||
APPLICATION
Microbiology and Cell Culture- Biochemical and Enzyme Research
- Chemical and Pharmaceutical Research
- Molecular Biology and Genetics
WHY CHOOSE US
- Factory direct sales with competitive price.
- Premium quality with CE & ISO certification.
- Strong product OEM & ODM customization capability.
- Promise production & on-time delivery.
- Perfect after-sales service, free product accessories.
- 15 years of experience in R&D and production of centrifugal extractor machine.
OUR FACTORY
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
PACKAGING & SHIPPING
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
CUSTOMER CASES
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe OQTSUPPLIES, we grow together!
