DESCRIPTION
Spectrophotometry is often used in measurements of enzyme activities, determinations of protein concentrations, determinations of enzymatic kinetic constants, and measurements of ligand binding reactions. The use of spectrophotometers spans various scientific fields, such as physics, materials science, chemistry, biochemistry,Chemical Engineering, and molecular biology.
FEATURES
1. High stability: Optimize the structure of the optical system and integrated aluminum alloy base structure, to ensure long-term stability and reliability of the instrument.
2. Intelligent degree is high: Dual CPU embedded system hardware design of super reliable,128*64 LCD display, rich instruction, without reading the manual, is simple and convenient to use; custom wavelength correction and automatic wavelength calibration function, replacing the artificial adjustment link; light source using time automatic accumulation, convenient view to understand, light source switch menu can be in the instrument does not use circumstances to choose to close, prolong the equipment service life.
3. Menu functions: Photometric measurement model, quantitative analysis, qualitative analysis, dynamic test, multi wavelength test.
4. Data processing is convenient: can store up to 1000 groups of experimental data, optional built-in and external printer output, or optional spectrum analysis software package and connected to the computer, to achieve more data processing and analysis functions.
Function:
1. Photometric measurement: to facilitate the measurement of the absorbance, transmittance, concentration of the sample at a specified wavelength.
2. Automatic quantitative measurement: to establish the standard curve, a first-order, zero order / two order and three order curve fitting, a variety of optional quantitative analysis standard curve method can store and call.
3. Qualitative measurement: do more to support the continuous recording of 100 data points, automatically find the maximum absorption peak wavelength position.
4. Kinetics measurement: enzymatic kinetic reaction rate calculation.
5. Multi wavelength measurement: data measurement with up to 10 wavelength points.
SPECIFICATIONS
| Model | OU-T3C | |
| Optical System | Single, Grating 1200 line/mm | |
| Wavelength Range | 190～1100nm | |
| Spectral Bandwidth | 2nm | |
| Wavelength Accuracy | ±1nm | |
| Wavelength Repeatability | ±0.2nm | |
| Photometric Accuracy | ±0.5%T；±0.002Abs（0~0.5Abs）；±0.004（0.5-1.0Abs）； | |
| Photometric Repeatability | ±0.2%T；±0.001Abs（0~0.5Abs）；±0.002（0.5-1.0Abs）； | |
| Stray Light | ≤0.05%T, @220nm/360nm | |
| Noise Level | ±0.0015Abs | |
| Stability | ±0.0015A/h@500nm | |
| Photometric Range | 0～200℅T，-0.301～3A,0～9999C(0-9999F) | |
| Light Source | Tungsten Lamp(Pre-aligned) | |
| Display | 128×64 Dots Array Graphic LCD | |
| System Language | English | |
| Output | USB1.1 Connecting to computer＆Parallel port for printer | |
| Power Requirement | AC90～250V/ 50～60Hz | |
| Dimensions(L×W×H) | 550×400×220 | |
| Weight | 13kg | |
WHY CHOOSE US
- Factory direct sales with competitive price.
- Premium quality with CE & ISO certification.
- Strong product OEM & ODM customization capability.
- Promise production & on-time delivery.
- Perfect after-sales service, free product accessories.
- 15 years of experience in R&D and production of centrifugal extractor machine.
OUR FACTORY
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
PACKAGING & SHIPPING
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
CUSTOMER CASES
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe OQTSUPPLIES, we grow together!
