DESCRIPTION
High speed centrifuge is a technique which involves the application of centrifugal force to separate particles from a solution. It is widely used in the field of medicine, life science, agriculture science, institute and so on, used in the area of protein precipitation, RNA extraction and clinical sample processing.
FEATURES
Advanced Control System, Excellent Separation
10 kinds of Accel/ Decel modes; User can set up the operate parameter by themselves, to achieve the best centrifugal result.
Short running function, easy to diversify centrifugation.
Proprietary SCT speed control technique, high efficiency.
Proprietary SBT soft brake control technique, to avoid mix up and ensure get maximum specimen.
Timing control, the centrifugal time can be free to choose minutes or seconds, to achieve optimal centrifugation.
High Safety, Ease of Ues
Auto Rotor identification, no need to select rotor number, avoid to over-speed running, ensure safety.
Protection functions of over temperature, over speed, door lid and imbalance switch off and so on, with sound and light alarm, to ensure human and instrument security.
Steel body, Stainless steel chamber, Steel Protective sleeve, three damping structure, to prevent accidents.
Optional rotor with aerosol-tight lid, the rotor can be high temperature and high pressure sterilization, to prevent biological pollution.
Friendly display, Humanity Operate
LCD. LED multi-screen display, program group, Accel/Decel, RPM/RCF, time, temperature and other parameters can be set without key combination, easy to operate;
Microprocessor control, operated data can be save automatically, can start the instrument with RCF directly, 40kind of self-defining programs can be stored and recalled, reduce duplication of operation.
Good Parts, Reliable and Long-lasting
Brushless frequency converter motor, super speed bearing and Freon-free compressor imported from Europe, high quality.
Aerospace rubber for damping, super duralumin alloy from Aluminum Corporation of Chin Limited (CHALCO), extend the service life of the machine.
SPECIFICATIONS
| Model | OQ-26 |
| Max. speed | 26500/min |
| Max RCF | 50000 x g |
| Max. Capacity | 120ml |
| Speed Accuracy | ±20r/min |
| Temperature Range | -20▫C ~ +40▫C |
| Temperature Accuracy | ± 1 ▫C |
| Time Range | 1s ~ 999min/999sec |
| Power supply | AC 220V 50HZ 18A |
| Noise | ≤65dB |
| Dimension | 670 x 750 x 440mm |
| Weight | 116kg |
Optional rotors:
| Model | No. | Capacity | Max. Speed (r/min) | Max. RCF (x g) | Dimension of tube (mm) |
| Angle rotor | 1 | 12 x 1.5ml | 26500 | 50000 | ∅ 10 x 42 |
| 2 | 18 x 0.5ml | 26500 | 50000 | ∅ 8 x 32 | |
| 3 | 10 x 5ml | 20000 | 27300 | ∅ 10 x 54 | |
| 4 | 12 x 10ml | 18000 | 30200 | ∅ 16 x81 |
APPLICATION
Biotechnology Biochemistry- Clinical Diagnostic Laboratories
- Pharmaceutical Chemical Industries
- Environmental and Research
WHY CHOOSE US
- Factory direct sales with competitive price.
- Premium quality with CE & ISO certification.
- Strong product OEM & ODM customization capability.
- Promise production & on-time delivery.
- Perfect after-sales service, free product accessories.
- 15 years of experience in R&D and production of centrifugal extractor machine.
OUR FACTORY
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
PACKAGING & SHIPPING
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
CUSTOMER CASES
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe OQTSUPPLIES, we grow together!
