DESCRIPTION
High temperature circulator is our design of a high temperature heat source, suitable for jacketed reactor, chemical reaction, high temperature distillation, semiconductor industry. High temperature circulating device made up of domestic defects of similar products, price is greatly lower than imported products.
FEATURES
1. High temperature circulator is suitable for fermenter, jacketed glass reactor and other things.
2. Outside circulation could rise the temperature in the jacket, therefore materials in which would react.
3.Resolution of digital display is 0.1°C.
4. Flow of outer circulation is 5~10L/min.
5. Our high temperature adopts the newest control technique, easy to operate, great stability and high precise.
6. The PID can be set by yourself.
7. Microcomputer intelligent could modify the error of measuring value.
SPECIFICATIONS
| Model | OGY-5 |
| Voltage | 220V 50Hz |
| Total power | 2060W |
| Pump motor power | 60W |
| Heating power | 2000W |
| Flow | 8L/min |
| Lifting height | 4M |
| Temperature range | RT~250°C |
| Temperature accuracy | ± 1°C |
| Joint port and tube | ɸ 12mm Pagoda joint, with 3m silicone pipe |
| Tank size | ɸ 250mmx250mm (H) about 12L |
| Tank oil volume | More than 9L |
| Dimension | 310x350x430mm |
| Net. Weight | 15kg |
| Package size | 380x380x480mm |
| Package weight | 17kg |
