DESCRIPTION
In addition to having the same functions as the IS-9 series, this constant temperature oscillator also achieves extremely precise temperature uniformity. In particular, the outer shell is made of light and strong material, which greatly reduces the total weight. The appearance is streamlined and more modern. At the same time, the thermal insulation performance is improved, and the variable frequency refrigeration technology is added to expand the temperature control range, reduce energy consumption, and provide a better platform for cell culture.
FEATURES
1. 7″ High-Res Color Touch Screen with intuitive graphic interface
2. Chamber design features smooth rounded internal corners for easy cleaning
3. Capacity is 6 x 5L Erlenmeyer shaker flasks
4. Infra-Red(IR) CO2 sensor for precise arid reliable CO2 detection
5. Optional WiFi and RDS485 monitorin and control
6. Set of UV f fights for easy sterilization
7. Audible and visual alarms
8. Mirror finish, pharmaceutical grade stainless steel chamber
9. Stackable design up to 3 units.
10. 25mm and 50mm orbit models available
SPECIFICATIONS
| Model | OIS-18 | OIS-18C | OIS-18C5 |
| Temp. Range | Room Temp. Minus 20℃~60℃ (Lowest Temp. is 4℃) | ||
| Power | ≤1000W | ||
| Speed | 0 (Stop)，30~300rpm | ||
| Speed Accuracy | ±1rpm | ||
| Orbit Diameter | φ26mm | φ50mm | |
| CO2 Sensor | NA | IR | |
| CO2 Control Range | NA | 0~20% | |
| CO2 Display Accuracy | NA | 0.1 | |
| CO2 Control Accuracy | NA | ±0.2%(@ 5%) | |
| Recover Time on the Temp. Close Door | ≤6min（@ 37℃） | ||
| Recover Time on the CO2 Close Door | NA | ≤6min（@ 5%） | |
| Application range of CO2 temperature | NA | 5~60℃ | |
| RH Type | Active Humidification | ||
| Max. Humidity | Ambient Rh~95% | ||
| Programing Numbers | 12 Sections | ||
| Disinfection | UV | ||
| Door Open Direction | Downward | ||
| Display | 7” Color Capacitance Touch Screen | ||
| Touch Screen Type | Capacitance Type | ||
| Auto-lock | Yes | ||
| Auto-close Screen | Yes | ||
| Protect Set Parameters | Passwords Protect | ||
| Display the Date | In a week | ||
| Date Curve Display | Temp. Curve, Speed Curve, | Temp. Curve, Speed Curve, CO2 Curve, RH Curve | |
| Max. Capacity | Clamp Capacity: 25mlx134/ 50ml×134/ 100ml×60/ 150ml×60/ 200ml×60/ 250ml×60/ 500ml×32/ 1000ml×22/ 2000ml×15/5000ml(Thomson)×6 Sticky Mat: 25mlx134/ 50ml×187/ 100ml×112/ 150ml×104/ 200ml×84/ 250ml×76/ 500ml×40/ 1000ml×28/ 2000ml×15/5000ml(Thomson)×8 | ||
| Max. Load | 20Kg | ||
| Platform Dimensions | 900×560mm | ||
| Temp. Uniformity | ≤±0.15℃（@ 37℃） | ||
| Temp. Volatility | ≤±0.12℃（@37℃） | ||
| Temp. Display Accuracy | 0.1℃ | ||
| Heat Power | ≤800W | ||
| Cool Power | ≤300W | ||
| Automatical Defrost | Yes | ||
| Timer | 0-999Hours59min. | ||
| U Disk Download Date | Yes | ||
| Date Store Years | ＞912 days | ||
| Date Store Time | 1 min. | ||
| Date Store Types | Time, Temp, Speed, Machine Status | Time, Temp, CO2%, Speed, RH, Machine Status | |
| Noise Level | ≤55dB | ||
| Water Sparge Resistant | Yes | ||
| Interface Languages | Chinese or English | ||
| Auto-run after Power Recovery | Yes | ||
| RH Control | Option | ||
| Passive Humidifier AutomaticWater | Option | ||
| Mobile Monitor and Control by WiF | Option | ||
| PC Monitor and Control by RS485 (Option) | Option | ||
| Net Weight | 200Kg | ||
| Internal Dimensions | 985×775×444mm | ||
| Outside Dimensions | 1355×875×535mm | ||
APPLICATION
Microbiology and Cell Culture- Biochemical and Enzyme Research
- Chemical and Pharmaceutical Research
- Molecular Biology and Genetics
