DESCRIPTION
For industrial and mining enterprises, laboratories, scientific research units, etc. for drying, baking, melting, sterilization.
FEATURES
1. The LED digital display with temperature control and timing function highlights the microcomputer temperature controller, and the temperature control is accurate and reliable.
2. The box body is made of mirror stainless steel or wire drawing material by argon arc welding. The outer part of the box is made of high quality steel plate material, which is beautiful and novel.
3. The hot air circulation system consists of a fan that can operate continuously at high temperatures and a suitable air duct, and the working temperature is uniform.
4. The use of imported fans and imported thyristors, long service life, can avoid frequent replacement.
5. Independent temperature limit alarm system, automatically interrupts when the temperature exceeds the limit, ensuring safe operation of the laboratory without accidents (optional)
6. Can be equipped with a printer or 485 interface for connecting to a printer or computer for real-time recording, temperature parameter changes (optional)
7. The “D” series is an intelligent ten-segment programmable LCD controller.
SPECIFICATIONS
| Model | DHG-9000 series | |||
| 9030A
9030AD (101-0A) |
9070A
9070AD (101-1A) |
9140A
9140AD (101-2A) |
9240A
9240AD (101-3A) |
|
| Voltage | 220V 50HZ | |||
| Temperature control range | Rt+10℃-250℃ | |||
| Temperature resolution | 0.1℃ | |||
| Constant temperature fluctuation | ±1℃ | |||
| Input power | 870W | 1570W | 2070W | 2470W |
| Working temperature | 5℃-40℃ | |||
| Liner size (mm) | 340*325*325 | 450*400*450 | 550*450*550 | 600*550*750 |
| Dimensions (mm) | 625*510*490 | 740*580*630 | 830*650*730 | 880*770*930 |
| Carrier bracket (standard) | Two | |||
| Timing range | 1-9999 minutes | |||
| Model | DHG-9003 series | |||
| 9023A
9023AD |
9053A
9053AD |
9123A
9123AD |
9203A
9203AD |
|
| Voltage | 220V 50HZ | |||
| Temperature control range | Rt+10℃-250℃ | |||
| Temperature resolution | 0.1℃ | |||
| Constant temperature fluctuation | ±1℃ | |||
| Input power | 870W | 1120W | 2070W | 2470W |
| Working temperature | 5℃-40℃ | |||
| Liner size (mm) | 340*325*300 | 420*400*345 | 550*450*550 | 600*600*650 |
| Dimensions (mm) | 625*540*490 | 720*580*530 | 830*650*730 | 880*770*825 |
| Carrier bracket (standard) | Two | |||
| Timing range | 1-9999 minutes | |||
| Model | DHG-9005 series | ||||
| 9035A
9035AD |
9055A
9055AD |
9075A
9075AD |
9145A
9145AD |
9245A
9245AD |
|
| Voltage | 220V 50HZ | ||||
| Temperature control range | Rt+10℃-300℃ | ||||
| Temperature resolution | 0.1℃ | ||||
| Constant temperature fluctuation | ±1℃ | ||||
| Input power | 970W | 1220W | 1670W | 2170W | 2870W |
| Working temperature | 5℃-40℃ | ||||
| Liner size (mm) | 340*325*325 | 420*400*345 | 450*400*450 | 550*450*550 | 600*550*750 |
| Dimensions (mm) | 625*510*490 | 720*580*530 | 740*580*630 | 830*650*730 | 800*770*930 |
| Carrier bracket (standard) | Two | ||||
| Timing range | 1-9999 minutes | ||||
APPLICATION
Research and Development-
Biotechnology Pharmaceutical
-
Food and Beverage Processing
-
Industrial Applications
-
Environmental Testing
-
Textile and Apparel Industry
WHY CHOOSE US
- Factory direct sales with competitive price.
- Premium quality with CE & ISO certification.
- Strong product OEM & ODM customization capability.
- Promise production & on-time delivery.
- Perfect after-sales service, free product accessories.
- 15 years of experience in R&D and production of centrifugal extractor machine.
OUR FACTORY
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
PACKAGING & SHIPPING
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
CUSTOMER CASES
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe OQTSUPPLIES, we grow together!
