DESCRIPTION
Autoclave is a device that uses high-temperature and high-pressure steam for sterilization. It is mainly used in the medical, laboratory and industrial fields to kill microorganisms such as bacteria, viruses, fungi and spores. Sterilizers can kill almost all microorganisms, such as the medical industry: sterilization of surgical instruments, dressings, etc. Laboratory industry: sterilization of culture media, glassware, etc. Industry: sterilization in food and drug production,etc.
FEATURES
1.Safer and more effective sterilization;
2.More simple and efficient;
3.More precise:Flexible exhaust methods and Verifiable;
4.Higher quality:Superior Material Quality and Good Sealing Performance.
SPECIFICATIONS
| Model | OS-65A/LS-65B /LS-65C | OS-90A/LS-90B/LS-90C | OS-115A/LS-115B/LS-115C |
| Capacity | 65L | 90L | 115L |
| Dimensions (L×W×H) | 664×660×994.5 mm | 664×660×994.5 mm | 664×660×1200 mm |
| Sterilization Chamber Dimensions | φ400×530 mm | φ400×730 mm | φ400×920 mm |
| Rated Power(W) | 2800W | 3400W | 4500W |
| Stainless Steel Baskets | φ370×200×2 | φ370×200&φ370×400 | φ370×400×2 |
| Working Voltage | AC 220±10%50Hz | ||
| Temperature Display Accuracy | 0.1℃ | ||
| Operating Environment | 5℃~40℃、relative humidity10%~85% | ||
| Sterilization Chamber Material | SUS304 stainless steel | ||
| Sterilization Working Temperature | 105℃~143℃ | ||
| Sterilization Time Pre-set Range | 1min~9999mins | ||
| Melting Temperature Pre-set Range | 60℃~100℃ | ||
| Melting Time Pre-set Range | 1min~9999mins | ||
| Insulation Temperature Pre-set Range | 45℃~60℃ | ||
| Insulation Time Pre-set Range | 1min~9999mins | ||
| Door Opening Temperature Pre-set Range | The solid,agar,and waste modes are from 40℃to 99℃,while the liquid mode is from 40℃to 80℃ | ||
| Clock Function Timer Pre-set Range | The operating time can be set(year,month,day,hour,minute),and it allows querying of the current time,total sterilization cycles,as well as fault occurrence times and error codes. | ||
| Pressure Gauge Display Range | 0~0.6Mpa | ||
| Pressure | The chamber design pressure is 0.35 MPa.Each unit comes with a corresponding product quality certificate and an original certificate issued by the special equipment manufacturing supervision and inspection department. | ||
| Pressure Safety Protection | Two independent pipelines for measurement and control,with dual mechanical and electronic pressure protection. | ||
| Exhaust Controland Water Tank | Fully automatic internal exhaust(exhaust temperature settings are detailed in the manual),with a built-in large-capacity steam condensate collection bottle and water tank. | ||
| Cover Opening Method and Interlocking Device | Unique eight-column interlocking device,flip-style switch cover,touch-type handle. | ||
| Controller and Memory Storage Function | Uses a microcomputer intelligent control system.It has 6 default operating modes,82 customizable modes,and 88 memory storage programs. | ||
| Safety Devices | Door lock interlock device;cover closure check;dry burn protection;water level sensor monitoring;electronic over pressure protection;mechanical safety valve;over temperature and heating protection;over current,short circuit protection;leakage protection;cooling lock;burn injury safety protection;automatic fault detection system. | ||
| Accessories | Condensate collection bottle,water separation plate,drainage hose,stainless steel basket. | ||
| Optional Accessories | Printer,cooling fan,item temperature sensor,USB output. | ||
| Series Description | A series(standard type )/ B series(auto water replenishment type) / C series(auto drying type) | ||
APPLICATION
Healthcare Facilities- Pharmaceutical Biotechnology
- Food Beverage Processing
- Scientific Research Institutions
WHY CHOOSE US
- Factory direct sales with competitive price.
- Premium quality with CE & ISO certification.
- Strong product OEM & ODM customization capability.
- Promise production & on-time delivery.
- Perfect after-sales service, free product accessories.
- 15 years of experience in R&D and production of centrifugal extractor machine.
OUR FACTORY
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
PACKAGING & SHIPPING
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
CUSTOMER CASES
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe OQTSUPPLIES, we grow together!
