DESCRIPTION
The instrument adopts magnetic bead separation technology and can be equipped with corresponding kits to automatically separate and purify high-purity nucleic acids from a variety of materials (blood, tissue, cells). The structure of the instrument is exquisitely designed, and the large-size touch screen is easy to operate. It greatly reduces manual operations in the sample processing process, optimizes the sample detection process, greatly shortens the time for virus nucleic acid extraction, and at the same time satisfies the requirements for safety prevention and control, easy operation, and rapid automation in the virus nucleic acid extraction process.
FEATURES
1. Two rows of 8-hole arrangement mode, can extract 1-8 samples at the same time;
2. Closed working area to prevent aerosol cross-contamination of samples between wells and batches;
3. Intelligent programming, flexible configuration, easy operation, to achieve different experimental needs of 1 to 8 channels;
4. The heating hole is fully wrapped in the hot well, which can effectively heat the liquid;
5. Ultra-quiet, decibels are less than 60dB;
6. Low magnetic bead loss and high extraction efficiency;
7. Super-fast: extraction can be completed in 11 minutes;
8. 8.8kg, easy to carry, more suitable for mobile laboratories;
SPECIFICATIONS
| Model | OK-08 |
| Working temperature | 10℃~40℃ |
| Relative humidity | ＜80% |
| Power supply | AC220V/50~60Hz |
| Sample throughput | 1~8 |
| Processing volume | 20μL~1000μL |
| Magnetic bead recovery efficiency | ＞98% |
| Number of magnetic rod | 8 |
| Strength of magnetic rod | Using military-grade rare earth magnetic materials>4000GS |
| Lysis/elution heating temperature | Room temperature~105℃ |
| Oscillating mixing | Multi-speed and multi-amplitude adjustable |
| Pollution control | Circulating air duct, HEPA filter system and UV disinfection |
| Operation interface | 5 inch color LCD display + touch operation |
| Network communication | Wireless WiFi |
| Dimensions (L*W*H) | 30cm*25.4cm*27.8cm |
| Program management | Preset programs to simplify the operation process and get started easily |
| Noise | ≤60dB |
| Extraction time | The operation time is short, and the extraction can be completed in 11 minutes at the fastest |
| Operating mode | No manual intervention is required, all experimental procedures are completed automatically, and the experimental results are stable and reliable |
| Certificate | ISO13485/ISO 9001:2015 |
WHY CHOOSE US
- Factory direct sales with competitive price.
- Premium quality with CE & ISO certification.
- Strong product OEM & ODM customization capability.
- Promise production & on-time delivery.
- Perfect after-sales service, free product accessories.
- 15 years of experience in R&D and production of centrifugal extractor machine.
OUR FACTORY
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
PACKAGING & SHIPPING
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
CUSTOMER CASES
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe OQTSUPPLIES, we grow together!
