DESCRIPTION
Widely used in the area of animal and plant molecular biology，cell biology, clinical application, bio- engineering, mass preparation and blood、protein precipitation. Separating the biology、viruses、sub- cell、cell and the chemicals in the cell.
FEATURES
1. Using microcomputer processor precision control, digital display speed, temperature, time and other parameters, button programming, 10 kinds of lifting rate for selection.
2. Door cover independent motor servo, reduce the labor intensity of the operator, overspeed, over temperature automatic protection, unbalance protection, the fuselage uses high quality steel structure; safe and reliable, easy to use.
3. The company’s unique spring taper sleeve is used to connect the rotor and the spindle. The loading and unloading rotor is quick and easy, non-directional, safe and reliable, and easy to use.
4. Equipped with a variety of rotors, and can be designed according to the test requirements of a variety of adapters, a multi-purpose machine.
5. Three-stage damping, the centrifugal effect is optimal.
SPECIFICATIONS
| Model | OQ-5 |
| Max speed | 5000r/min |
| Max RCF | 3860×g |
| Max volume | 4×750ml |
| Power supply | AC 220V 50HZ 10A |
| Timer | 1～99min |
| Noise | ≤58dBA |
| Speed accuracy | ±50r/min |
| Dimension | 655×500×790 |
| Net weight | 108KG |
Optional rotors:
| No. | Rotor type | Max. speed (r/min) | Volume (ml) | Max. RCF (xg) |
| No31495 | Swing rotor (Round cup) | 4000 | 2×750ml (500ml Test cup) | 3380 |
| No31496 | Swing rotor (Round cup) | 4000 | 4×750ml (500ml Test cup) | 3380 |
| 40301—40308 Adaptor | ||||
| Swing rotor(elliptical cup) | 4000 | 4×500ml | 3380 | |
| No31392 | Swing rotor(Round cup) | 4000 | 4×300ml(250ml Test cup) | 2920 |
| 40401—40408 Adaptor | ||||
| No31389 | Swing rotor | 4000 | 4×22×5ml(Vacuum tube) | 2840 |
| 4×31×5ml(Radioimmunoassay tube) | ||||
| No31390 | Swing rotor | 4000 | 4×22×7ml(Vacuum tube) | 3140 |
| 4×31×7ml(Radioimmunoassay tube) | ||||
| No31491 | Swing rotor(Bucket rotor) | 4000 | 2×4×96hole | 2490 |
| No31494 | Swing rotor(Bucket rotor) | 4000 | 4×4×96hole | 2840 |
| No31376 | Swing rotor(Bucket rotor) | 4000 | 2×3×48hole | 2300 |
| No31479 | Swing rotor(Square cup) | 4000 | 4×500ml | 3310 |
| 40101—40108 Adaptor | ||||
| No31493 | Swing rotor | 4000 | Cream bottle | 3830 |
| No30627 | Angle rotor | 5000 | 30×15ml | 3830 |
| No30638 | Angle rotor | 5000 | 6×15ml | 2540 |
| No30607 | Angle rotor | 5000 | 12×15ml | 3080 |
| No30639 | Angle rotor | 5000 | 24×15ml | 3500 |
| No30640 | Angle rotor | 5000 | 4×50ml | 2520 |
| No30611 | Angle rotor | 5000 | 6×50ml | 2850 |
| No30641 | Angle rotor | 5000 | 12×50ml | 3860 |
| No30642 | Angle rotor | 4000 | 24×50ml | 2970 |
| No30613 | Angle rotor | 5000 | 4×100ml | 2630 |
| No30614 | Angle rotor | 5000 | 6×100ml | 3130 |
| No30643 | Angle rotor | 4000 | 12×100ml | 2970 |
APPLICATION
Biotechnology Biochemistry-
Clinical Diagnostic Laboratories
-
Pharmaceutical Chemical Industries
-
Environmental and Research
WHY CHOOSE US
- Factory direct sales with competitive price.
- Premium quality with CE & ISO certification.
- Strong product OEM & ODM customization capability.
- Promise production & on-time delivery.
- Perfect after-sales service, free product accessories.
- 15 years of experience in R&D and production of centrifugal extractor machine.
OUR FACTORY
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
PACKAGING & SHIPPING
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
CUSTOMER CASES
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe OQTSUPPLIES, we grow together!
